Overall Dimension L*W*H |
2070mm*1150mm*1175mm |
|
Ground clearance |
200mm |
|
Max Speed |
≥60km/h |
|
Climbing Ability |
≥35° |
|
Specification of Front wheel |
25*8-12（38F） |
|
Specification of Rear wheel |
25*10-12（45F） |
|
Distance between front wheel |
860mm |
|
Distance between rear wheel |
860mm |
|
Distance between front and rear wheel |
600mm |
|
Seat high |
900mm |
|
Distance between front axle and rear axle |
1235mm |
|
Gross weight |
350kg |
|
Dry weight |
300kg |
|
system front/rear Brake |
Disk/Disk |
|
Engine |
One Cylinder/Four Stroke |
|
Cylinder dia..*Working stroke |
71mm*71mm |
|
Efficient Capacity |
367ml |
|
Rated Power and Rotate Speed |
17.2KW/7600r/min |
|
Max Torque and Rotate Speed |
26N.m/6000r/min |
|
Compressing Ratio |
2.444-0.829 |
|
Gearshift Mode |
CVT/Reverse |
|
Transmission |
4 drive/Shaft drive , manual front drive |
|
Starting System |
Electric |
|
Cooling System |
Water- Cooling |
|
Fuel tank |
13 |
|
Loading |
12/20 36/40H |
|
Packing measure |
1950*1160*860 |
